Motor
Giant SyncDrive Pro2 85Nm, powered by Yamaha, PedalPlus 6-Sensor technology
Controller
Giant RideControl Ergo3, grip integrated remote
Display
Giant RideControl GO, frame integrated LED console Optional wireless ANT+ display
Battery
Giant EnergyPak 800Wh, 22700 Lithium cell technology, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production Giant EnergyPak Plus 250 range extender compatible (exculde S size)
Charger
Giant EnergyPak 6A smart charger, 60% in 3:00h
Connectivity
Giant RideControl App enabled ANT+ wireless display signal with e-bike profile
Sizes
S, M, L, XL
Colours
Gloss Cordovan/Matte Black
Frame
ALUXX SL-grade aluminium, Advanced Forged Composite Upper Rocker, 160mm Maestro suspension system, 'Boost' 148x12mm, Universal Derailleur Hanger
Fork
RockShox ZEB Select 29er, 170mm travel, Charger RC damper, 15x110 Boost, Maxle Stealth, E-bike Approved
Shock
Fox Float X Performance, EVOL Large Volume sleeve, 2-position lever, 205x62.5mm Trunnion mount, custom tuned
Handlebar
Giant Contact Trail, 35x800mm
Grips
Giant Tactal Pro-E, single lock-on
Stem
Giant Contact SL 35
Seatpost
Giant Contact Switch, dropper, 30,9mm (S:125/M:150/ L&XL:170)
Saddle
Giant Romero Trail
Pedals
Flatpedal
Shifters
Shimano Deore SLX
Front Derailleur
MRP HD2 co-moulded chain guide
Rear Derailleur
Shimano Deore SLX, 12-speed, Shadow+
Brakes
Shimano SLX BR-M7120, 4-piston, hydraulic disc, 203mm
Brake Levers
Shimano SLX, I-spec EV
Cassette
Shimano HG-M6100, 10-51T, 12-speed
Chain
KMC e.12 Turbo, EcoProteq, e-bike optimised
Crankset
Praxis Wavetm 36T Cold Forged 4130 premium steel Praxis e-Cadet+ custom forged crankarm set (S/M:160, L/XL:165)
Bottom Bracket
n/a
Rims
Giant AM 29" [F] 27.5"[R], Tubeless ready, 30mm inner width
Hubs
Shimano MT410 Boost, Center-Lock, [F] 110x15 [R] 148x12mm Micro-Spline Drive Body Thru-axle
Spokes
Sapim E-Lite [R] Race [F], e-bike optimised
Tyres
Maxxis Minion DHF 29x2.6" foldable, Tubeless, EXO+, 3C MaxxTerra[F]Maxxis High Roller II 27.5x2.5" foldable, Tubeless, DoubleDown, 3C MaxxTerra Compound [R]
Extras
Tubeless kit (liquid, valves, levers, manual, tool)
Lighting
-
Lock
Torx 25 Battery Lock with built-in Torque limiter
Carrier
-
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality
