Sizes
XS, S: MX only, M, L: 29" F&R out of the box, MX compatible
Colours
Soap Suds
Frame
ALUXX SL-grade aluminium front and rear triangles, 150mm Maestro Suspension, 3 position flip chip, integrated down tube storage
Fork
Marzocchi Bomber Z1, 160mm, Rail damper, Boost 15x110 Kabolt, tapered, 44mm offset
Shock
Fox Float Performance 185x55, custom tuned for Liv
Handlebar
Giant Contact TR35, alloy, 35mm, 20mm rise
Grips
Liv Tactal Pro Single Lock-On
Stem
Giant Contact SL, 35mm
Seatpost
Giant Contact Switch dropper, remote XS: 100mm travel/ 30.9 x 345mm S: 125mm travel / 30.9 x 395mm M&L: 150mm travel / 30.9 x 440mm
Saddle
Liv Sylvia
Pedals
PEDALS NOT SUPPLIED
Shifters
Shimano Deore, 1x12
Front Derailleur
N/A
Rear Derailleur
Shimano Deore, Shadow +
Brakes
Shimano BR-MT420, hydraulic, Shimano RT-66 rotors [F]203mm, [R]180mm
Brake Levers
Shimano BL-MT401
Cassette
Shimano Deore M6100, 10x51
Chain
KMC X12
Crankset
Praxis Cadet, steel chain ring 30t, 52mm chainline
Bottom Bracket
Praxis, press fit
Rims
Giant AM, tubeless ready, sleeve-joint, 30mm inner width XS/S: [F] 29, [R] 27.5 M/L: [F] 29, [R] 29
Hubs
alloy
Spokes
Stainless steel
Tyres
[F]: Maxxis Minion DHF 29x2.5WT, 3C Max Terra, EXO, TR, tubeless Size XS and S, [R]: Maxxis Dissector 27.5x2.4WT, 3C Max Terra, EXO, TR, tubeless Size M and L, [R]: Maxxis Dissector 29x2.4WT, 3C Max Terra, EXO, TR, tubeless
Extras
MRP chain guide, 3M tailgate protector, factory tubeless set up, integrated down tube storage bag, max tyre size 2.5", max chainring size 32t
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
