Motor
Giant SyncDrive Pro2 Magnesium 85Nm, PedalPlus 6-Sensor technology
Controller
Giant RideControl Ergo3, grip integrated remote
Display
Giant RideControl GO, frame integrated LED console Optional wireless ANT+ display
Battery
Giant EnergyPak 400Wh, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production, Giant EnergyPak Plus 200 range extender compatible
Charger
Giant EnergyPak 4A smart charger, 60% in 1:45
Connectivity
Giant RideControl App enabled ANT+ wireless display signal with e-bike profile
Sizes
S, M, L, XL
Colours
Gloss Sea Sparkle
Frame
Advanced-grade composite frame, Advanced-grade rear triangle, Advanced forged composite upper rocker, 140mm Maestro suspension system
Fork
Fox 36 Float Performance E-Tuned, 29er, 150mm travel, 44mm offset, Grip Damper, Kabolt-X 110
Shock
Fox Float Performance, EVOL Large Volume sleeve, 2pos, 185x52.5mm Trunnion mount, custom tuned
Handlebar
Giant Contact SL 35 Trail, 35x780mm
Grips
Giant Tactal Pro-E, tapered design, 135mm Ø28~30mm (S/M) 142mm Ø29~32mm (L/XL)
Stem
Giant Contact SL 35
Seatpost
Tranz-X Rad+ 30,9mm, 30mm travel adjustable (S:120-150mm, M:140-170mm, L/XL:170-200mm)
Saddle
Giant Romero, Neutral
Pedals
PEDALS NOT SUPPLIED
Shifters
Shimano SLX 1x12
Front Derailleur
MRP HD2 co-moulded chain guide
Rear Derailleur
Shimano SLX
Brakes
Shimano SLX, BR-M7120, 4-piston, hydraulic disc, 203mm [F/R]
Brake Levers
Shimano SLX, I-spec EV
Cassette
Shimano, CS-M6100, 10-51T, 12-speed
ChainK
MC e.12 Turbo, EcoProteq, e-bike optimised
Crankset
Praxis N.W. 36T Cold Forged 4130 premium steel Praxis e-Cranks (Q-factor=168, S:160, M/L:165, XL:170)
Bottom Bracket
n/a
Rims
E-TRA Hookless Tubeless ready Alloy 29 [F] / 27.5 [R] 30mm inner width
Hubs
E-TRA MTB Alloy Hub, 6 Bolt, 110x15 [F] / 148x12 Shimano Micro-Spline Drive Body Pawl Driver (Pawl 36x2 T) Thru-axle [R]
Spokes
Sapim E-Lite [R] Race [F], e-bike optimised
Tyres
Maxxis Minion DHF 29X2.50"" Foldable, TLR, EXO [F] Maxxis Dissector 27.5x2.4"" Foldable, TLR, EXO [R]
Extras
Tubeless kit (liquid, valves, levers, manual, tool) Inner tube supplied
Lighting
Optional:- Giant Recon series e-bike lights available and direct connectable
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
